4 MP ColorVu MD 2.0 Fixed Turret Network Camera
Hikvision Internet Protocol (IP) Camera Available

4 MP ColorVu MD 2.0 Fixed Turret Network Camera

Contact for price
Model DS‐2CD1347G2‐L
Brand Hikvision
Category Internet Protocol (IP) Camera
The Hikvision DS-2CD1347G2-L is a powerful 4MP ColorVu network camera engineered to provide high-quality full-color monitoring around the clock. Unlike conventional cameras that switch to black-and-white at night, Hikvision's ColorVu technology enables the camera to capture bright and colorful images even in extremely low-light conditions.

Equipped with a 1/3" Progressive Scan CMOS sensor, the camera delivers crystal-clear video with a maximum resolution of 2560 × 1440 (4MP). Its F1.0 super aperture lens and built-in warm white supplemental light help maintain excellent image brightness and detail throughout the night, making it ideal for areas where color information is essential for identification and evidence collection.

The DS-2CD1347G2-L supports H.265+ video compression, reducing storage requirements and network bandwidth usage while maintaining superior image quality. Advanced image enhancement technologies including 120 dB WDR, 3D DNR, BLC, and HLC ensure balanced and detailed footage in challenging lighting environments.

Built for outdoor use, the camera features an IP67-rated weatherproof housing, protecting it from dust, rain, and harsh weather conditions. The compact turret design minimizes glare and simplifies installation. With support for Power over Ethernet (PoE), deployment becomes faster and more cost-effective with a single cable handling both power and data transmission.

The Hikvision DS-2CD1347G2-L is suitable for residential buildings, retail stores, parking areas, warehouses, schools, and office security systems that require dependable full-color surveillance day and night.

Camera Specifications

Image Sensor 1/3" Progressive Scan CMOS
Max. Resolution 2560 × 1440
Min. Illumination Color: 0.001 Lux @ (F1.0, AGC ON),0 Lux with light
Shutter Time 1/3 s to 1/100,000 s
Day & Night 24/7 color imaging
Angle Adjustment Pan: 0° to 360°,tilt: 0° to 75°,rotate: 0° to 360°

Lens

Lens Type Fixed focal lens, 2.8 and 4 mm optional
Focal Length & FOV 2.8 mm, horizontal FOV: 96°, vertical FOV: 52°, diagonal FOV: 113°
4 mm, horizontal FOV: 75°, vertical FOV: 40°, diagonal FOV: 89°
Lens Mount M12
Iris Type Fixed
Aperture F1.0
Depth Of Field 2.8 mm: 2 m to ∞
4 mm: 2.7 m to ∞

Illuminator

Supplement Light Type White Light
Supplement Light Range Up to 30 m
Smart Supplement Light Yes

Video

Main Stream 50 Hz:
20 fps (2560 × 1440)
25 fps (1920 × 1080, 1280 × 720)

60 Hz:
20 fps (2560 × 1440)
24 fps (1920 × 1080, 1280 × 720)
Sub-Stream 50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360)
60 Hz: 24 fps (1280 × 720, 640 × 480, 640 × 360)
Video Compression Main stream: H.265+/H.265/H.264+/H.264
Sub-stream: H.265/H.264/MJPEG
Video Bit Rate 32 Kbps to 8 Mbps
H.264 Type Baseline Profile,Main Profile,High Profile
H.265 Type Main Profile
Bit Rate Control CBR, VBR
Region of Interest (ROI) 1 fixed region(s) for main stream

Audio

Audio Type Mono Sound
Environment Noise Filtering Yes
Audio Sampling Rate 8 kHz/16 kHz
Audio Compression G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/AAC-LC
Audio Bit Rate 64 Kbps (G.711 ulaw)/64 Kbps (G.711 alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 160 Kbps (MP2L2)/16 to 64 Kbps (AAC-LC)

Network

Protocols TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, NTP, IGMP, IPv6, UDP, QoS, FTP, SMTP
Simultaneous Live View Up to 6 Channels
API Open Network Video Interface (Profile S, Profile T, Profile G (only -F model supports)),ISAPI,SDK
User/Host Up to 32 users
3 user levels: administrator, operator, and user
Security Password protection, complicated password, watermark, basic and digest authentication for HTTP, WSSE and digest authentication for Open Network Video Interface, security audit log, host authentication (MAC address)
Client iVMS-4200, Hik-Connect
Web Browser Plug-in required live view: IE 10, IE 11,
Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+


Wide Dynamic Range (WDR) 120 dB
SNR ≥ 52 dB
Day/Night Switch Day,Night,Auto,Schedule
Image Enhancement BLC,HLC,3D DNR
Image Settings Rotate mode,saturation,brightness,contrast,sharpness,gain,white balance,adjustable by client software or web browser
Privacy Mask 4 programmable polygon privacy masks

Interface

Ethernet Interface 1 RJ45 10 M/100 M self-adaptive Ethernet port
On-Board Storage model supports built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB
Built-in Microphone Yes
Reset Key Yes

Event

Basic Event Motion detection (support alarm triggering by specified target types (human and vehicle)),video tampering alarm,exception
Linkage Upload to FTP/memory card (-F), notify surveillance center, send email, trigger recording (-F), trigger capture

General

Power 12 VDC ± 25%, 0.4 A, max. 5 W,Ø5.5 mm coaxial power plug,
PoE: 802.3af, Class 3, 36 V to 57 V, 0.2 A to 0.15 A, max. 6.5 W
Material Metal & Plastic
Dimension Ø109.9 mm × 103.6 mm (Ø4.3 × 4.1\")"
Startup and Operating Conditions -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)

Product Documents

User Manual

PDF 6 downloads

Download
Quick Start Guide

PDF 5 downloads

Download
DataSheet

PDF

Download
