4 MP ColorVu 3.0 Fixed Bullet Network Camera
Contact for price
Model
DS‐2CD1047G3‐LIU
Brand
Hikvision
Category
Internet Protocol (IP) Camera
Overview
The Hikvision DS-2CD1047G3-LIU is a professional-grade 4MP bullet IP camera engineered to provide dependable security for homes, offices, warehouses, retail stores, and commercial facilities. Featuring a high-resolution 4MP sensor, the camera captures sharp and detailed images with excellent clarity.
Its Smart Hybrid Light technology automatically switches between infrared and white light illumination, providing superior night vision performance while reducing unnecessary light pollution. With illumination distance up to 30 meters, the camera ensures effective monitoring even in complete darkness.
The built-in microphone records audio along with video, providing additional evidence and enhancing overall security. Advanced human and vehicle classification minimizes false alarms caused by irrelevant movements, improving event accuracy and monitoring efficiency.
Supporting H.265+ video compression, the camera reduces storage requirements and bandwidth usage without compromising image quality. The rugged IP67-rated weatherproof housing protects the camera from dust and harsh weather conditions, making it suitable for both indoor and outdoor installations.
The Hikvision DS-2CD1047G3-LIU is an ideal solution for users seeking high-performance surveillance with intelligent features and reliable 24/7 protection.
Its Smart Hybrid Light technology automatically switches between infrared and white light illumination, providing superior night vision performance while reducing unnecessary light pollution. With illumination distance up to 30 meters, the camera ensures effective monitoring even in complete darkness.
The built-in microphone records audio along with video, providing additional evidence and enhancing overall security. Advanced human and vehicle classification minimizes false alarms caused by irrelevant movements, improving event accuracy and monitoring efficiency.
Supporting H.265+ video compression, the camera reduces storage requirements and bandwidth usage without compromising image quality. The rugged IP67-rated weatherproof housing protects the camera from dust and harsh weather conditions, making it suitable for both indoor and outdoor installations.
The Hikvision DS-2CD1047G3-LIU is an ideal solution for users seeking high-performance surveillance with intelligent features and reliable 24/7 protection.
Specifications
Camera Specifications
| Image Sensor | 1/3" Progressive Scan CMOS |
|---|---|
| Max. Resolution | 2560 × 1440 |
| Min. Illumination | Color: 0.0005 Lux @ (F1.0, AGC ON),0 Lux with light |
| Shutter Time | 1 s to 1/100,000 s |
| Day & Night | IR Cut Filter |
| Angle Adjustment | Pan: 0° to 360°,tilt: 0° to 90°,rotate: 0° to 360° |
Lens
| Lens Type | Fixed focal lens, 2.8 and 4 mm optional |
|---|---|
| Focal Length & FOV | 2.8 mm, horizontal FOV 95.7°, vertical FOV 51.7°, diagonal FOV 113.7° 4 mm, horizontal FOV 79.6°, vertical FOV 43.2°, diagonal FOV 93.2° |
| Lens Mount | M12 |
| Iris Type | Fixed |
| Aperture | F1.0 |
| Depth Of Field | 2.8 mm: 1.7 m to ∞ 4 mm: 1.6 m to ∞ |
Illuminator
| Supplement Light Type | IR, White Light |
|---|---|
| Supplement Light Range | Up to 30 M |
| Smart Supplement Light | Yes |
| IR Wavelength | 850 nm |
Video
| Main Stream | 50 Hz: 25 fps (2688 × 1520, 2560 × 1440, 1920 × 1080, 1280 × 720) 60 Hz: 24 fps (2688 × 1520, 2560 × 1440, 1920 × 1080, 1280 × 720) |
|---|---|
| Sub-Stream | 50 Hz: 25 fps (1280 × 720,640 × 480,640 × 360) 60 Hz: 24 fps (1280 × 720,640 × 480,640 × 360) |
| Video Compression | Main stream: H.265+/H.265/H.264+/H.264 Sub-stream: H.265/H.264/MJPEG |
| Video Bit Rate | 32 Kbps to 16 Mbps |
| H.264 Type | Baseline Profile, Main Profile, High Profile |
| H.265 Type | Main Profile |
| Bit Rate Control | CBR, VBR |
| Region of Interest (ROI) | 1 fixed region for main stream and sub-stream |
| Scalable Video Coding (SVC) | H.264 and H.265 encoding |
Audio
| Audio Type | Mono Sound |
|---|---|
| Audio Compression | G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/AAC-LC/MP3 |
| Audio Bit Rate | 64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 160 Kbps (MP2L2)/16 to 64 Kbps (AAC-LC) |
| Audio Sampling Rate | 8 kHz/16 kHz |
| Environment Noise Filtering | Yes |
Network
| Protocols | TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, RTCP, NTP, IPv4, IPv6, IGMP, UDP, QoS, FTP, SMTP |
|---|---|
| Simultaneous Live View | Up to 6 Channels |
| API | ONVIF (Profile S, Profile G, Profile T),ISAPI,SDK |
| Security | Password protection, complicated password, watermark, basic and digest authentication for HTTP, WSSE and digest authentication for Open Network Video Interface, security audit log, host authentication (MAC address) |
| User/Host | Up to 32 users 3 user levels: administrator, operator, and user |
| Client | iVMS-4200;Hik-Connect |
| Web Browser | Plug-in required live view: Chrome 80+, Firefox 80+, Edge 89+, Safari 13+ Plug-in free live view: Chrome 80+, Firefox 80+, Edge 89+ |
| Image Settings | Rotate mode,saturation,brightness,contrast,sharpness,gain,white balance, adjustable by client software or web browser |
|---|---|
| Day/Night Switch | Day,Night,Auto,Schedule |
| Wide Dynamic Range (WDR) | 120 dB |
| SNR | ≥ 52 dB |
| Image Enhancement | BLC,HLC,3D DNR |
| Privacy Mask | 4 programmable rectangular privacy masks |
Interface
| Ethernet Interface | 1 RJ45 10 M/100 M self-adaptive Ethernet port |
|---|---|
| On-Board Storage | N/A |
| Built-in Microphone | Yes,1 built-in microphone |
| Built-in Speaker | N/A |
Event
| Basic Event | Motion detection (support alarm triggering by specified target types (person and vehicle)), video tampering alarm, exception |
|---|---|
| Linkage | Upload to FTP,notify surveillance center, send email, trigger recording |
General
| Power | 12 VDC ± 25%, 0.55 A, max. 6.6 W,Ø5.5 mm coaxial power plug, reverse polarity protection, PoE: IEEE 802.3af, Class 3, max. 8 W |
|---|---|
| Power | 12 VDC ± 25%, 0.55 A, max. 6.6 W,Ø5.5 mm coaxial power plug, reverse polarity protection, PoE: IEEE 802.3af, Class 3, max. 8 W |
| Material | Metal & Plastic |
| Dimension | 69.1 mm × 66.9 mm × 172.9 mm (2.7" × 2.6" × 6.8") |
| Startup and Operating Conditions | -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
